Fabrication Systems
Lumabuilt is the SMART choice in ACM fabrication. We provide full service for any of our TESTED Systems: A1000, A1000NF, and A2000.
• Architectural ACM sheets for interior or exterior applications
• FR (Fire Resistant mineral core) standard
• Available in 4mm (standard), 6mm thickness (upon request)
• Face & Backer Sheet – 0.5 mm (0.0197″), A3000 Series Aluminum Alloy
• Finishes: PVDF – Solid & Mica, specialty Woodgrain Finishes also available
• Standard ACM sheet size is 62” x 196“; A1000 Maximum fabricated panel is 60″ x 194″; A1000NF Maximum fabricated panel is 58″ x 192″
• Matching flat sheets available in 36” x 120” x 0.032, 0.040, & 0.050 Aluminum (min order qty 125 sheets /color-gauge)
• Variety of colors and finishes in standard offering & color matching services available
• PPG Paint Finish 20 Year Warranty / Panel 10 Year Warranty
• Fully ICC certified (ESR-5448)
A1000
A1000 ACM SYSTEM – EXPOSED RIVETS
A1000 is an aluminum composite material system available in sheets or a fully fabricated rainscreen. Extrusions are available as components for field fabrication. A1000 is a fully integrated and tested system. Standard FR (Fire Resistant mineral core), Finishes: Pro finish 500 (PPG Industries Duranar) Standard, Mica and Metallic with clear coat, PPG paint warranty- 20 years standard (inquire for added duration)
A1000NF
A1000NF ACM SYSTEM – NON EXPOSED RIVETS
A1000NF is an aluminum composite material system available in sheets or a fully fabricated rainscreen. Extrusions are available as components for field fabrication. A1000NF is a fully integrated and tested system. Standard FR (Fire Resistant mineral core), Finishes: Pro finish 500 (PPG Industries Duranar) Standard, Mica and Metallic with clear coat, PPG paint warranty- 20 years standard (inquire for added duration)
A2000
A2000 WET SEAL SYSTEM
A2000 is an aluminum composite material system available in sheets or a fully fabricated rainscreen. Extrusions are available as components for field fabrication. A2000 is a fully integrated and tested system. Standard FR (Fire Resistant mineral core), Finishes: Pro finish 500 (PPG Industries Duranar) Standard, Mica and Metallic with clear coat, PPG paint warranty- 20 years standard (inquire for added duration)
Manufacturing Partners
At Lumabuilt, we partner with several ACM sheet manufacturers, fabricating their sheets into one of our three tested systems. ALUCOBOND and Alpolic are just a few of our partners.
